Single Pulley Tension Sensor Stainless Steel High Precision Cable Textile Manufacturing Dynamometer (0-50N)
4.9 (147 items)
Limited Time Sale$62.39 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221349932 | Release Date | 2026/05/03 | List Price | $41.60 | Model Number | 221349932 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Single Pulley Tension Sensor Stainless Steel High Precision Cable Textile Manufacturing Dynamometer Features: High precision and good stability Easy installation, can install pulleys of different specifications Stable anti-interference signal Flexible installation, simple debugging, accuracy up to 0.002 Widely used in optical fibre, yarn, cable, tape, etc. Specifications: Name: Single Pulley Tension Sensor Range: 0-10N/0-20N/0-30N/0-50N/0-100N/0-200N/0-500N (optional) Output sensitivity: 2.0+0.05mV/V Zero output: +1%F.S. Nonlinearity: 0.2%F.S. Hysteresis: 0.2%F.S. Repeatability: 0.2%F.S. Creep: (30 minutes) 0.3%F.S. Temperature sensitivity drift: 0.1%F.S. Zero temperature drift: 0.1%F.S. Response frequency: 1kHz Material: stainless steel Impedance: 350Ω Insulation resistance: ≥5000MΩ/100V DC Operating voltage: 5-15V Operating temperature range: -20-80°C Safe overload: 150% Ultimate overload: 200% Cable specification: φ5x3m Ultimate cable tension: 98N Package includes: 1 x Single Pulley Tension Sensor
- High precision and good stability
- Easy installation, can install pulleys of different specifications
- Stable anti-interference signal
- Flexible installation, simple debugging, accuracy up to 0.002
- Widely used in optical fibre, yarn, cable, tape, etc.
| Manufacturer | top-tool |
|---|
